Parent Layer: Storm

Name: Storm Outlets

Display Field: GIS.SPATIAL.DRN_Outlet.assetid

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description: This table contains information describing the inlet and the outlet structures and their locations in the District of Lake Country. An drainage inlet is where the stormwater flows into a structure and an outlet is where the stormwater flows out from the structure. Each structure is assigned to its unique AssetID for documentation and asset management purposes. Along with the function type of the structures, additional information including the location description, the relevant As-Built information under the comments, the ownership, the current status, the important dates and associated personnel if available.

Copyright Text: District of Lake Country, Regional District of Central Okanagan

Default Visibility: true

MaxRecordCount: 2000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 324496.1228
YMin: 5542342.846
XMax: 331548.2910000002
YMax: 5558000.247
Spatial Reference: 26911  (26911)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• GIS.SPATIAL.DRN_Outlet.OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• GIS.SPATIAL.DRN_Outlet.rotation ( type: esriFieldTypeDouble, alias: Rotation )
• GIS.SPATIAL.cgStormOutletsClass.IDField ( type: esriFieldTypeString, alias: AssetID, length: 20 )
• GIS.SPATIAL.cgStormOutletsClass.OwnerField ( type: esriFieldTypeString, alias: Owner, length: 40 )
• GIS.SPATIAL.cgStormOutletsClass.DiameterField_Amount ( type: esriFieldTypeString, alias: Diameter, length: 10 )
• GIS.SPATIAL.cgStormOutletsClass.GrateTypeField ( type: esriFieldTypeString, alias: Grate Type, length: 20 )
• GIS.SPATIAL.cgStormOutletsClass.MaterialWallField ( type: esriFieldTypeString, alias: Wall Material, length: 20 )
• GIS.SPATIAL.cgStormOutletsClass.PipeMaterialField ( type: esriFieldTypeString, alias: Pipe Material, length: 20 )
• GIS.SPATIAL.cgStormOutletsClass.ShapeField ( type: esriFieldTypeString, alias: Shape, length: 20 )
• GIS.SPATIAL.cgStormOutletsClass.OMSurl ( type: esriFieldTypeString, alias: Link to Cartegraph, length: 255 )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
