Parent Layer: Water

Name: Water Valves

Display Field: GIS.SPATIAL.WTR_Valves.assetid

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description: This table contains information describing the water valves and their locations in the District of Lake Country. Different types of valves have different functions. For example, gate valve is used for permit or prevent the flow of water and is typically for on/off control rather than flow regulation. Air release valve is used to release the unwanted air during the water system operation to protect against against unwanted surges and maintain system efficiency. Each water valve is assigned to a unique AssetID for documentation and the purpose of asset management. Along with their physical properties, the water valves also have location description and relevant As-Built information in the comments, the current status, the important dates, as well as the associated personnels if available.

Copyright Text: District of Lake Country, Regional District of Central Okanagan

Default Visibility: true

MaxRecordCount: 2000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 323951.71109999996
YMin: 5541654.3221
XMax: 332499.6090000002
YMax: 5556960.8429
Spatial Reference: 26911  (26911)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: GIS.SPATIAL.cgWaterValves.TypeField
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: Ball
  Label: Ball
  Description: N/A
  Symbol:

• Value: Bulk Outlet
  Label: Bulk Outlet
  Description: N/A
  Symbol:

• Value: Butterfly
  Label: Butterfly
  Description: N/A
  Symbol:

• Value: Gate
  Label: Gate
  Description: N/A
  Symbol:

• Value: Pressure Tank
  Label: Pressure Tank
  Description: N/A
  Symbol:

Transparency: 0
Labeling Info:

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• GIS.SPATIAL.WTR_Valves.objectid ( type: esriFieldTypeOID, alias: OBJECTID )
• GIS.SPATIAL.WTR_Valves.rotation ( type: esriFieldTypeDouble, alias: Rotation )
• GIS.SPATIAL.cgWaterValves.IDField ( type: esriFieldTypeString, alias: Asset ID, length: 20 )
• GIS.SPATIAL.cgWaterValves.OMSurl ( type: esriFieldTypeString, alias: Link to Cartegraph, length: 255 )
• GIS.SPATIAL.cgWaterValves.TypeField ( type: esriFieldTypeString, alias: Valve Type, length: 20 )
• GIS.SPATIAL.cgWaterValves.DepthField ( type: esriFieldTypeString, alias: Valve Depth, length: 20 )
• GIS.SPATIAL.cgWaterValves.SizeField ( type: esriFieldTypeString, alias: Valve Size, length: 30 )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates
