Parent Layer: Storm

Name: Storm Mains

Display Field: GIS.SPATIAL.DRN_Mains.assetid

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: This table contains information describing different types of drainage mains and their locations in the District of Lake Country. The drainage main is underground pipe that carry the stormwater and snowmelt. Each drainage main is assigned to its unique AssetID for documentation and the purpose of asset management. Along with the properties, the drainage main also have location description, the relevant As-Built drawings information under the comments, the current status, ownership information, important dates and the associated personnels if available.

Copyright Text: District of Lake Country, Regional District of Central Okanagan

Default Visibility: true

MaxRecordCount: 2000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 324496.1228
YMin: 5542096.6587
XMax: 342070.31010000035
YMax: 5555392.4347
Spatial Reference: 26911  (26911)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [197, 0, 255, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:
Label Placement: esriServerLinePlacementAboveAlong
Label Expression: N/A
Use Coded Values: true
Symbol:
Color: [0, 0, 0, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 8
Font Family: Calibri
Font Style: normal
Font Weight: normal
Font Decoration: none

Min. Scale: 10000.0
Max. Scale: 0.0

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• GIS.SPATIAL.DRN_Mains.objectid ( type: esriFieldTypeOID, alias: OBJECTID )
• GIS.SPATIAL.cgStormMains.IDField ( type: esriFieldTypeString, alias: Asset ID, length: 200 )
• GIS.SPATIAL.cgStormMains.ServiceStatusField ( type: esriFieldTypeString, alias: ServiceStatusField, length: 200 )
• GIS.SPATIAL.cgStormMains.OwnerField ( type: esriFieldTypeString, alias: Owner, length: 200 )
• GIS.SPATIAL.cgStormMains.MaterialField ( type: esriFieldTypeString, alias: Material, length: 200 )
• GIS.SPATIAL.cgStormMains.DiameterField_Amount ( type: esriFieldTypeString, alias: Diameter, length: 200 )
• GIS.SPATIAL.cgStormMains.FlowTypeField ( type: esriFieldTypeString, alias: Flow Type, length: 200 )
• GIS.SPATIAL.cgStormMains.OMSUrl ( type: esriFieldTypeString, alias: Link to Cartegraph, length: 200 )
